Automatic Dry Type Transformer Foil Winding Machine Programmable
Brand Name:STT
Certification:CE
Model Number:BRJ600-2
Minimum Order Quantity:1 set
Delivery Time:45 days
Payment Terms:T/T, L/C
Contact Now
Add to Cart
Verified Supplier
Address:
No.126,Yanshan West Road,Chengxiang Town,Taicang City,Jiangsu Province,China
Supplier`s last login times:
within 33 hours
Product Details
Company Profile
Product Details
Programmable PLC Control Automatic Dry Type Transformer Foil Winding Machine
Description of transformer foil winding machine BRJ600-2
Automatic dry type transformer foil winding machine BRJ600-2 is for
winding foil coils to make dry type transformer. TIG welding unit
is adopted to weld foil and bus bar together. The foil winding
machine can be used to wind not only copper foil but also aluminium
foil. The maximum width of the foil wound by the transformer foil
winding machine is 600mm.
Quick details of transformer foil winding machine BRJ600-2
- Maximum foil width 600mm
- TIG welding
- Cu foil thickness 0.2 - 2.0mm
- Al foil thickness 0.3 - 3.0mm
- Two foil decoilers
- Two insulation decoilers
- Winding motor power 11kw
- Rotating speed 26rpm
Main parameters of transformer foil winding machine BRJ600-2
| Coil Shape: | oval, circle and rectangular |
| Foil Material OD.: | 1,000mm |
| Foil Material ID.: | 500mm |
| Conductor Decoiler Number: | 2 pcs |
| Conductor Decoiler Length: | 650mm |
| Decoiler Expanding Range: | 400-520mm |
| Winding Power: | 11KW |
| Winding Shaft Size: | 80×80×950 mm |
| Rotating Speed: | 0 - 26 Rpm |
| Insulation Decoiler Number: | 2 pcs |
| Insulation Material OD.: | ≤400mm |
| Insulation Material ID.: | 76mm |
| Insulation Paper Width: | 650mm |
| End-fill Strip Feeder: | 6 pcs |
| Edge Alignment System: | Photoelectric sensing automatic rectifying deviation |
| User Interface: | 10inch (254mm) touch screen |
| Counting Turns Range: | 0 - 9999.9 |
Fig 1: Transformer foil winding machine BRJ600-2's front view
Fig 2: Transformer foil winding machine BRJ600-2's foil decoiler
