IEC60898-1 AC Circuit Breaker Mechanical Shock Multiple Perspectives Tester
Product overview
The mechanical shock test equipment is based on the relevant
requirements of IEC60898-1, IEC61009-1, IEC60934:2007.
Design and manufacture, suitable for circuit breaker products, to
verify the impact resistance of exposed parts that may be subjected
to mechanical shock during normal use of the circuit breaker.
The equipment adopts PLC control, touch screen operation,
motor-driven cam mechanism to control the lifting action, the
interval time can be preset, the whole machine adopts a
floor-standing structure, easy to operate, practical and beautiful.
Main parameters
| The parameter name | Parameter data |
| The power supply voltage | 220V (AC) 50Hz |
| control | PLC control, 7 inch color touch screen operation |
| drive | Motor drive mechanism CAM |
| Test station | Simplex bit |
| Spiral spring | Elastic coefficient 25N/mm |
| Base A, platform B, plank C | Hardwood, painted black |
| Drop height | 40mm |
| turntable | Can be fixed by rotation of 12-30° |
| Weight weight | 100g*10 PCS, 150g*5 PCS, 200g*5 PCS, |
| Number of test | 0-999999 times, touch screen preset |
| Drop interval time | 0-999999s, touch screen preset |
| Equipment dimensions and weight | WDH = 900 * 600 * 1350, about 110 kg |
Equipment principle
Designed in accordance with IEC60898-1, the mounting plate equipped with the circuit breaker is lifted by
the motor control cam, and instantly falls freely to the metal stop
plate equipped with a spiral spring with an elastic coefficient of
25N/mm. This reciprocating 50 times, the sample is switched to
another 3 90-degree directions through the turntable to repeat the
test 50 times.
