Digital Paper Package Box Window Box Patching Machine

Automatic Digital Cutter Paper Package Box Window Patching Machine

Technical Specifications:

Film material:
Applicable to PET, PVC, PP, OPP, PE, Asha and even paper.
It can also be used for films with special effects such as light film, dumb film, flash film, colored film, printed film, UV filter film and fluorescent film.

1. Sizing Part(gluing):
The Gluing Section consists of the chrome-plated glue roller, glue separation plate, side guide and glue mould roller.
The Gluing Section can be easily pulled out ,it's easy to set and clean.
The glue separation plate is adjustable to control the glue area and amount.
In case of the machine shutdown, the cylinder will lift the glue roller and then the machine will be driven by the other separate motor ,to avoid the leaking of the glue.
Option of pre-make ready table is available, Operator can set up the mould outside of the machine. It's convenient and time saving.

2. Paper collecting part (delivery stacker)
The belt at the Delivery Section is wide. Operator can adjust the height of the belt and the finished products are aligned in a straight line.
Belt speed can also be adjusted to be synchronized with the machine speed.

3. Feeder part (paper feeding)
The machine is equipped with lower belt feeding system, with the choice of option which is pilling lifting system and belt lifting system.
The characteristic of the belt lifting system is high speed thus increasing capacity.
The characteristic of the pilling lifting system is that the feeding belt can be run continuously while boxes can go through the upward/downward movable pilling lifting system. This pilling lifting system is flexible in capable of feeding different boxes without scratching the boxes.
The feeding system design is an advance technology. Synchronous belt feeder is equipped with suction system. At the chain adjusting section there are four feeding chains.
There is a feeding gate at the feeder which allows you to adjust upper rail without additional tool. This upper rail is made of flat steel and is connected to the middle part of the frame.
This system is reliable which ensure the registration of all, cardboard and chain is accurate.
Even when there is serious jam, the position is precise and you can use micro-adjustment to adjust.

4. Window patching part
Boxes are delivered from the gluing section to the window patching section by suction.
Suction is run individually and registered by sensor. When there is blank sheet, the suction table will go down to avoid sticking of glue on the belt.
Operator can adjust the volume of suction air according to the size of the box.
The suction cylinder is made of special material. It is smooth so that the speed of patching is high and there will be no scratch on the plastic film.
When the knife cylinder is rolling, it intercrosses with another fixed knife bar and hence cutting the plastic film like "scissors". The cutting edge is flat and smooth.
The knife cylinder is with adjustable blowing or suction system to ensure the plastic film is patched on the window of the box accurately.

Vedios on Youtube:https://www.youtube.com/channel/UCV_4Z0lLAy49T0u8dvF-eDw/


FAQ:
1. What are your main products ?

EcooGraphix is a leading and professional Supplier for Prepress Solution , Printing Materials and Post Packing Equipment.
Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP , CTCP , VLF CTP and CTCP, Flexo CTP , Processor , Offset Plates ,inks , blankets , postpress Packing equipments and so on.
There are thousands CTPs installed worldwide. Our partners in USA,Canada,Mexico,Colombia,Turkey,Hungary,South Africa and so on are very pleased with our Technician Support service and product performance.
We can also supply the thermal CTP plate(single and double layers),positive CTCP plates(single and double layers) and Chemistry free CTP plate.
You can get the prepress equipment and consumables all in one and no worry about the after-sales service from our company.
2. Where is your factory ?
Our CTP machine factory is located in Hangzhou city , which is about 1.5 hour by train from Shanghai.
You are warmly welcomed to visit our factory!
3. What is your warranty for the CTPs ?
Three years' Laser Head and main spare parts for the CTPs, One year for the Processor.
If the customer uses Ecoographix CTP plate with the CTP machine,we will provide the Lifetime Warranty.
4. What is the Lead Time?
Usually 10-30 days, and we will try our best to meet your demands.
5. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose V9.
6. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions,we will be at your disposal 7x24 hours.
