Concrete Cube Compression Strength Testing Machine

Brand Name:BOTO
Certification:CE ISO
Model Number:BT-D-A
Minimum Order Quantity:1set
Delivery Time:1-15 days,to be negotiated
Payment Terms:L/C, T/T
Contact Now

Add to Cart

Verified Supplier
Location: Shanghai Shanghai China
Address: Room 2304, Fortune Plaza, No. 5616 Caoan Road, Anting Town, Jiading District, Shanghai
Supplier`s last login times: within 41 hours
Product Details Company Profile
Product Details

Concrete Cube Compression Strength Testing Machine

Electro-hydraulic pressure testing machine is developed and manufactured on the basis of GB/ t2611-2007 general technical requirements for testing machines and GB/ t50081-2002 test methods for mechanical properties of ordinary concrete. This series of testing machine takes hydraulic pressure as power and manual loading to test the compressive mechanical properties of concrete, brick, stone and other building materials. It can display loading force value and loading speed value digitally. It can be configured with computer to display loading curve and carry out data collection and processing.

Technical ParametersBT-D-2000BT-D-2000A
Maximum test force(KN)20002000
Test accuracyLevel1Level1
Piston stroke(mm)Pad adjustmentmanual adjustment
Compression surface maximum spacing(mm)Hydraulic pressureHydraulic pressure
Diameter of clamp sample(mm)350350
Stretching maximum distance(mm)Φ225240*240
Whole power(mm)Φ295350*350
Host Dimensions(KW)0.750.75
Total weight (kg)900*400*1250900*400*1250
Flat sample holding thickness(mm)920920
Loading control method8080
