PT100 Temperature Module Temperature Sensor Temperature Sensor Module
Description PT100 Temperature Module Temperature Sensor Temperature Sensor Module
PT100 Temperature Module Temperature Sensor Temperature Sensor Module is with 24V power supply, two-wire system of integrated transmitter. Products adopts imported integrated circuits, the thermal resistance or thermocouple signal amplification and conversion into 4-20mA or 0-10mA output current, or 0 ~ 5V output voltage. One armored transmitter can directly measure the gas or liquid temperature is particularly suitable for low temperature range measurement, to overcome the condensation of water on the impact of temperature measurement.
Specification PT100 Temperature Module Temperature Sensor Temperature Sensor Module
| thermal resistance measurement range | PT100:-200～650℃；CU50:-50～150℃ |
| Thermocouple measurement range | K type:300～1200℃； E type:200～800℃；S type:600～1600℃ |
| Output siginal | 4-20mA,0-10mA,0-10V,0-5V |
| Measurement accuracy | Thermocouple measurement:0.2～0.3% Thermocouple:1～2% |
| Temperature drift | 0.025%/℃ |
| Power supply | +12VDC or +24VDC±10% |
| Work environment | 0～70℃ |
| Storage Conditions | -40～+85℃ |
