Waterproof Capacitive Inductive Proximity Sensor Capacitance Level Sensor 12vdc
Brand Name:yunyi
Certification:ce
Model Number:M12
Minimum Order Quantity:100
Delivery Time:10days
Payment Terms:L/C, D/A, D/P, T/T, Western Union
Contact Now
Add to Cart
Verified Supplier
Address:
Rm. 1203-1, Bldg. B, Xian Xinsilu International E-Commerce Industrial Park, No. 9, Gangwu Road, Int'l Port District
Supplier`s last login times:
within 38 hours
Product Details
Company Profile
Product Details
12vdc Waterproof Capacitive Inductive proximity sensor capacitance level sensor
Description of 12vdc Waterproof Capacitive Inductive proximity sensor Capacitance level sensor
12vdc Waterproof Capacitive Inductive proximity sensor mainly used for the detection of the target and the location of the object, is divided into inductive, capacitive, reed sensor, photoelectric, ultrasonic and other forms, can detect metal, nonmetal, liquid and other materials.
Features of 12vdc Waterproof Capacitive Inductive proximity sensor Capacitance level sensor
12vdc Waterproof Capacitive Inductive proximity sensor Capacitance level sensor
Basic parameters
Installation type: Unshielded type
Detect range: 15mm ±10%
Distance setting: 0-13mm
Detect object: magnetic metal
Standard detect object: Iron 30*30*1mm, 50*50*1mm
Response frequency: DC:0.5khz, AC: 25HZ
Material: shell: Nickel plated brass, detect surface: ABS
Protection grade: IP67
Applications of 12vdc Waterproof Capacitive Inductive proximity sensor Capacitance level sensor
12v dc Waterproof Capacitive Inductive proximity sensor
* Various location detection of machinery process center
* Bottle lid detection
* Stopper detection of grinding machine
* Arm location detection of robot
* Spacing detection
* Inspection of the exiating of milk inside the paper package
Selection Guide of 12vdc Waterproof Capacitive Inductive proximity sensor Capacitance level sensor
Detected object | magnetic metal | inductive proximity sensor |
conventional object | capacitive proximity sensor | |
photoelectric sensor | ||
Detecting range | less than 50mm | proximity sensor |
greater than 50mm | photoelectric sensor | |
Detection mode | magnetic | hall effect sensor |
reed sensor | ||
infrared | photoelectric sensor | |
Installation dimension | cylindrical | cylindrical type |
square | square type | |
groove | groove type | |
Connection | cable | cable type |
connector | connector type |
Installation of 12vdc Waterproof Capacitive Inductive proximity sensor Capacitance level sensor
Waterproof Capacitive Inductive Proximity Sensor Capacitance Level Sensor 12vdc
