Printer Long Squeegee Automatic Batch Cleaning Machine For Screen Printing Process
Brand Name:SHENHUA
Certification:CE,UL
Model Number:SME-280
Minimum Order Quantity:1 set
Delivery Time:30~40 days
Payment Terms:L/C, T/T, D/A, D/P, Western Union, MoneyGram
Contact Now
Add to Cart
Verified Supplier
Location:
Dongguan Guangdong China
Address:
Building 3, No.12, Wusha Zhenyuan Road, Chang'an Town, Dongguan City, Guangdong Province
Supplier`s last login times:
within 14 hours
Product Details
Company Profile
Product Details
High efficient 900mm length ink screen printing squeegee batch cleaning machine is a new type oil squeegees auto cleaning machine. Screen printing machine squeegees are very hard to clean beause the corners at the 2 end of them; cracks of squeegees and fixing plates are also hard to be cleared.
SME-280 is an off-line, compact, energy-saving , batch cleaning screen printing squeegee cleaning machine. SME-280 can automatically complete the cleaning, rinsing, drying process in one chamber by just push" start" key.
Machine Features:
1. Special designed to clean printing oil, silver paste and other organic and inorganic contaminations on Squeegees .
2. Ultrasonic and spray clean at the same time to clean all the oil off from the squeegees.
3. Clean,rinse,dry process, thoroughly clean, standby and ready to use at any time.
4. 6 squeegee racks : can clean 6pcs 900mm squeegees in one time.
5. State of the process is visible through a large observation window.
6. Clean detergent heat system heat cleaning detergent to a certain temp, raise cleaning efficiency and reduce clean time.
7. Easy operation interface, quick setting clean parameters. Different passwords can be set.
8. Inner filter makes detergent used repeated. .
9. Totally SUS304 structure, very firm and attractive.
Machine Spec:
| Item | SME-280 Spec |
| Squeegee numbers | 4pcs of 900mm squeegees one time, 8 pcs of 400mm one time |
| clean lqiuid tank capacity | 120L |
| rinse water tank capacity | 120L |
| Clean time | 5~10min |
| Rinse time | 1~2min |
| Dry time | 10~30min |
| cleaning liquid heat temp | Room temp~60ºC |
| Dry temp | Room temp~99ºC |
| water temp | Room temo~60ºC |
| Cleaning liquid filter | 1um |
| Rinse water filter | 1um |
| clean/ rinse pump | 1.1KW |
| ultrasonic power | 1.2KW |
| Power/air supply | AC380V/50A/50HZ,30KW;0.5Mpa |
| Machine size | L1600 x W1600 x H1400(mm) |
| Machine weight | 600KG |
Comparison pictures before and after cleaning:
Printer Long Squeegee Automatic Batch Cleaning Machine For Screen Printing Process
