22kW EV Type 2 Socket
Brand Name:ANS
Certification:TUV, CE
Model Number:ANS-T2-22kW
Minimum Order Quantity:1pc
Delivery Time:15days
Payment Terms:L/C, D/A, D/P, T/T, Western Union, MoneyGram
Contact Now
Add to Cart
Verified Supplier
Location:
Chengdu China
Address:
No.1,Floor 3,No. 366,North Section of Hupan Road,Chengdu
Supplier`s last login times:
within 34 hours
Product Details
Company Profile
Product Details
Type 2 Charging Station Socket 32A 480V 22kW Electric Vehicle Connection TUV CE Type 2 Socket with Protective Door
Features
- Comply with EC62196-2:2010standard
- Nice appearance,with protective door,with protective cover, support after instllation
- Mechanicalife:no-load plugin/pllout>100 times
- Operating temperature: -30℃~+50℃
- Material:Thermopatic materials
- Terminal: copperallo, siver plated
- Inner core: thermoplastic
- Superior protection performance, protection level up to IP55(afterinsertion)
Electrical Performance
| Rated current | 32A |
| Operation voltage | 480V |
| Terminaltemperature rise | < 50K |
| Electical esistance | 200v |
DC Contact Resistance | 0.5 mQ Max |
| Cable pecification | 5*6mm²+2*0.75mm2 |
Movement: 1 plug inserted to trigger the drive block and latch to
move outward, the protective door rotates around the pivot point A
under the action of the extension spring
2 pull out the plug drive block and latch back under the action of
the spring, the protection of the door back under the action of the
pivot point C
Protection: 1. Separate trigger latch protection door in the role
of the pivot point C does not move,then play a protective role
2 separate trigger drive block to protect the door in the role of
the latch does not move, then play a protective role
Certification:TUV,CE
