Multiple Type Cap Compatible High Speed Automatic Capping Machine 100ml-1L

Multiple Type Cap Compatible-High Speed Automatic Capping Machine 100ml-1L

Pick and place type Rotary Capping Machine is used for closing plastics screw caps, especially for the caps with lock ring. It is widely used in industries like foodstuff, pharmacy, daily chemical, cosmetic, fertilizer, etc.
Automatic rotary cappers are designed to handle a wide range of caps including screw caps, press-on caps, tamper-proof caps, aerosol over caps, inserts, ROPP caps, twist-off caps onto plastic and glass containers. Rotary cappers have much higher speed capabilities than in-line capping machines.
PLC control system, rotary type structure, the machine is with the function of automatic cap feeding, loading, and closing.
The containers are fed onto the rotary screw capper and are separated and positioned on individual capping stations. The caps are presorted and fed on the sliding table of the machine. The continuously rotating chucks are lowered over the cap to pick up and secure the caps, then apply the caps to the containers. When the preset applied torque value is achieved, the magnetic clutch disengages, the chuck releases the cap and the closed container is discharged from the machine.
With 6 mechanical hands, the model is suitable for multi-geometry containers. It dispatches caps at a fast speed without any cap reversed. Supplying cap system and mechanical hands work together in phase. When the cap is tightened, bottle and cap standstill relatively, and the clutch separates immediately so that able and not apt to be damaged.

Technical parameters:

Bottle Inlet Part

Capping Feeding Part

3. Detection and rejection of no aluminum foil cap

4. The cap sorter

Electric Cabinet

Key Features:

Cap change parts complete set to run a different size cap(option)

Carbon steel base mounted on adjustable floor levelers for easy alignment

Bearing frame and all surface components manufactured in 304 stainless steel

Magnetic clutch capping heads for screw caps complete with pick & place cap system

Caps in chute photocell, the machine will not work if there are no caps present on the chute

Automatic cap feeder, chute, and applicating head

Electrical socket for optional elevator feed

Safety guarding with interlock devices

Cap elevator to load the cap feeder automatically(option)

JiangSu Enterprise profile of Jiangsu Jinwang Intelligent Sci-tech Co., Ltd.

Jiangsu Jinwang Intelligent Sci-tech Co., Ltd.(JWIM), established in 2005, is a high-tech enterprise specializing in R&D, manufacturing, sales and service of pesticides, fertilizers, veterinary drugs and feed intelligent factories (intelligent processing, intelligent packaging, intelligent storage and intelligent office). Over the past 16 years, Jinwang has served nearly 3000 agrochemical preparation enterprises at home and abroad. At present, the company has a registered capital of 20 million, covers an area of 100 mu, a construction area of 100000 square meters, has more than 600 employees and more than 300 professional and technical personnel. Jinwang has passed the EU CE certification, CMP certification, ISO9001 quality management system certification, OHSAS18001 occupational health and safety management system certification and ISO14001 environmental management system certification, and has obtained more than 70 patent certificates. The production scale and technical level are among the forefront of domestic peers.The products are exported to more than 50 countries and regions such as the United States, Malaysia, Vietnam, Japan, Egypt, Turkey, Thailand, South Korea, Saudi Arabia, Austria and Australia. Jinwang is rated as high-tech enterprise and famous trademark of Jiangsu Province.
In recent years, Jinwang intelligent has closely focused on the market, continuously carried out research and development of new products, professionally focused on the integration of intelligent factories of agricultural and veterinary preparations. To make this industry specialized, refined, thorough, strong and unparalleled, and become the first brand in the world! At present, Jinwang is a leading enterprise in the domestic agricultural and veterinary preparation packaging machinery industry. And the domestic market share is more than 30%.
Our mission: to accelerate the arrival of intelligent era of the global agricultural and veterinary preparation industry
Our vision: to build a world-class Internet service platform for intelligent factories of agricultural and veterinary preparations
Core code of conduct: 1. Customer first; 2. Continuous innovation; 3. Coordinated operations; 4. Keep promises; 5. Details are king; 6. Data speaks.
Our original intention: 1. Create value for customers; 2. Create happiness for employees; 3. Contribute to society.
