Product Details
Company Profile
Product Details
UV LED Curing Lamp COB 80W Chiller UV Lamp LED UV Curing Machine uv led lamp
UV LED Curing Lamp Product Description
The item may be administered along with either Water-cooling or
even wind-cooling strategy.
Various other treating dimension and also current may be created according your requirment, inluding mix
wavelenth unique wavelenth as well as treating dimension.
Various other treating dimension and also current may be created according your requirment, inluding mix
wavelenth unique wavelenth as well as treating dimension.
Greater functionality and also lowered consumption.
Apply in a number of printing industries, coating, in addition to sticky.
Apply in a number of printing industries, coating, in addition to sticky.
| Item | UV LED Curing lamp COB 80W |
| Power | 80w |
| Color | UV |
| Diode Brand | DC, LG |
| Diode type | COB smd type |
| Size | 44mm*27mm |
| Luminous Size | 37mm*8mm |
| Chip Material | Epileds |
| Wavelength | 365nm,385nm,395nm,405nm |
| Cooling scheme | Water cooling |
| Application | Apply in various printing industries, painting, and glue. |
| Lifespan (hours) | 20000-30000 |
| Warranty | 1 years |
| Place of Origin | Guangdong, China |
Attention should be paid to welding high-power UV LED:
1) The welding time should not exceed 3S;
2) Welding temperature should be less than 260 degrees Celsius.
3) Reflow welding is allowed only once.
4) When welding, distinguish positive and negative polarity, and
avoid lens to avoid damage to lens..
5) Do a good job of heat dissipation measures, especially
high-power UVLED as far as possible to ensure
adequate radiator area
6) In order to prolong the lifetime of ultraviolet light emitting
diodes, it is recommended to use a stable
constant current driving power supply or IC instead of a constant
voltage driving power supply or IC.
Thank you for your attention
