WDS-700 BGA Reballing Station Automatic Operation For Mobile Phones Chips

Higher automatic function

Newest WDS-700 is the updated system with 5 modes.It’s Remove,Mount,Weld,Manual and Semi-auto.The mode can be changed freely.It can be used under automatic,semi-auto & manual mode.

Independent 2 heating zones temperature control system

1.The upper and lower hot air heating,which can heat up at the same time from the top of he component to the bottom of the PCB;temperature precision control within ±1℃.8 segment temperature control independently.

2.Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system;4 temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved;temperature can be tested precisely through external measurement interface,curves can be analysed,set and correct on the touch screen at any time.

Precision optical alignment system

Using high definition and adjustable CCD color optical alignment system,beam split,amplification,lessening,fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 ” high definition LCD monitor.

Multi-functional and humanized operation system

1.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement.

2.X,Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.

Superior safety protection function

With the alarm function, after the BGA welding the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter having password protection to prevent any modification.

Technology parameter

Shenzhen Wisdomshow Technology Co., Ltd. is an enterprise integrating R & D, production, sales, trade and service. The company is located in the west of Bao'an District, Shenzhen. Thanks to convenient transportation conditions, such as the proximity to Shenzhen International Airport, the coastal port and land terminal transportation, our company has a variety of superior opportunities for modern trade at home and abroad. Our core industry It is a BGA rework system and peripheral auxiliary equipment, specializing in providing SMT process solutions, providing advanced production equipment, testing equipment, rework and excellent technical services for domestic and foreign customers. The company's main products are: AI, BGA hot air rework station, 3D solder paste thickness detector, temperature curve test, AOI, parts counter, PCB curve distribution machine, and electronic accessories. The company appoints talents, continuously introduces high-end talents, employees have a strong team spirit, has built an online sales platform and communication system, and guarantees to provide excellent after-sales service, so that the company has won good reputation and evaluation at home and abroad. Adhering to the business philosophy of "professionalism, innovation and integrity", we have won the trust and support of our customers in the BGA rework system and peripheral auxiliary equipment and consumables. The company's products have applied for design patents, and the products have passed CE certification, and are exported to Japan, South Korea, North Africa, Vietnam, Southeast Asia, the Middle East, Europe and the United States and other countries. Since the establishment of the company, we have won the unanimous recognition of our customers with the business philosophy of "professionalism, integrity, excellence, customer first". In order to continuously expand the scale of the company, we sincerely look forward to cooperating with you.
