Long Range High Gain RF Linear Power Amplifier with SMA-Female Ports for 900-980MHz Applications
Brand Name:Kimpok
Certification:CE certification
Model Number:KP-RFPA900
Minimum Order Quantity:1
Delivery Time:3-7 working days
Payment Terms:T/T,Paypal,L/C
Contact Now
Add to Cart
Verified Supplier
Location:
Shenzhen Guangdong China
Address:
Rm616, Kingsignal signal connection technology industrial park, No. 50 Baolong 2nd road, Longgang district, Shenzhen, Guangdong Province, China
Supplier`s last login times:
within 1 hours
Product Details
Company Profile
Product Details
Detail Information(75-100W RF Linear Power Amplifier 900-980MHz
50dB Gain 27VDC)
Place of Origin:
Shenzhen,China
Brand Name:
Kimpok
Certification:
CE certificate
Model Number:
KP-RFPA900
Highlight:
900-980MHz RF linear power amplifier
50dB gain RF amplifier
27VDC RF power amplifier
Trading Information(75-100W RF Linear Power Amplifier 900-980MHz
50dB Gain 27VDC)
Minimum Order Quantity:
1
Price:
Negotiation
Packaging Details:
International standard packing
Delivery Time:
3-7 working days
Payment Terms:
L/C,T/T,Paypal
Supply Ability:
5000pcs/month
Product Description(75-100W RF Linear Power Amplifier 900-980MHz
50dB Gain 27VDC)
Long Range 75-100W RF Linear Power Amplifier 900-980MHz
48.5dBm-50dBi PA DC 27V with SMA-Female Input&Output Ports
Product Overview
Professional RF linear power amplifier with high gain and output power for long-range applications in the 900-980MHz frequency range.
Key Specifications
| Parameter | Value |
|---|---|
| Model Number | KP-RFPA900 |
| Frequency Range | 900-980MHz (customizable) |
| Gain | 50dBi |
| Max RF Output Power | 50dBm /100W |
| Working Voltage | 27VDC (27V-28V) |
| Working Current | 10A |
| RF Connectors | SMA-Female |
| Dimensions | 210*110*25mm |
| Weight | 2kg |
Detailed Technical Specifications
| No. | Item | Specification |
|---|---|---|
| 1 | Frequency Range GSM | 900-980MHz (Customized) |
| 2 | Gain | 50dB |
| 3 | Max RF Output Power | 48.5dBm-50dBm |
| 4 | Input Range | ≤10dBm |
| 5 | Gain Adjust Range | 31dB |
| 6 | Gain Adjust Step | 1dB |
| 7 | In-Band Ripple | 2dB |
| 8 | Input/Output VSWR | Less 1.5 |
| 9 | Working Voltage | 27VDC |
| 10 | Working Current | 75W: 8A 100W: 9.1A |
| 11 | RF Input/Output Ports | SMA-Female |
Optional Features
- Shut-down over High VSWR
- Shut-down over High temperature
- Auto-restart after 30 seconds against shut-down
- DB9 Male connector with RS485 interface (includes free PC software)
- DB15 Female connector with various control and monitoring functions
Product Dimention(75-100W RF Linear Power Amplifier 900-980MHz 50dB
Gain 27VDC)
Manufacturing Information
Brand Name: Kimpok Technology
Place of Origin: Shenzhen, China
Certification: CE Certification
Port: Hong Kong/Shenzhen
Ordering Information
Minimum Order Quantity: 1 Piece
Price: Negotiation
Packaging: International standard packing
Delivery Time: 3-7 work days
Payment Terms: T/T, PayPal, Alipay
Supply Ability: 5000/month
