Name: Customization Pressure Sensor Module Convenient High Precision Pressure Sensor
Brand: SongFast
Price: 3.60 USD

China Categories

Home Products Suppliers Selling leads

English

Home /Products /Machinery /Cleaning Equipment /High Pressure Cleaner /

Customization Pressure Sensor Module Convenient High Precision Pressure Sensor

Brand Name:SongFast

Certification:ISO 9001, IATF 16949

Minimum Order Quantity:500pcs

Delivery Time:30-day lead time

Payment Terms:T/T

Place of Origin:Dongguan,China

Contact Now

Add to Cart

Dongguan SongFast Electronic Technology Co.,Ltd.

Verified Supplier

Location: Dongguan Guangdong China

Address: Room 907, FengShou Building, No.97 Guanchang Road, Xiaobian, Chang'an Town, Dongguan City, Guangdong Province, China.

Supplier`s last login times: within 15 hours

View Contact Details

Product Details Company Profile

Product Details

High-Performance Pressure Sensor Module for Precise Industrial Measurements

Main Features

Integrated design with high product stability
Supports customization of various output signals such as current, voltage, IIC, etc.
Easy and convenient to use
Excellent EMC protection and reverse polarity protection

Product Parameters

Parameters	Electrical characterisitics
Series Name	RS186MV/RS183MV
Type	Flush diaphragm module
Size (diameter x height)	φ18x(6.3-6.95)/φ18x (3.3-3.78)mm
Supply voltage	5.0 ± 10% DC (optional 8-32V DC )
Working current	＜10 mA
Output signal	0.5-4.5V DC
Over voltage	＜ 12V DC
Operating temperature	‘-40 ℃~125℃
Storage temperature	’-40℃~150 ℃
Nonlinearity	0.25% FS Max
Hysteresis & repeatability	0.25% FS Max
Output accuracy	※ ± 1.0% Vcc@0-70℃, ± 3.0% Vcc@-40 ℃~125℃
Response time	＜ 10 mS
Zero-point long term stability@25℃	Zero@25℃:＜0.25 FSO (no time accumulation)
Cycle life	5 million pressure cycles@2-5Hz, 0~full scale pressure~0, 15 ~35℃
Working medium	oil, water, gas, refrigerant, coolant, chemical solvents, detergents, etc

Product Range

RS186MV/RS183MV
Thickness 18x6.35mm Series
Product model	Working pressure range	Product thickness H	Overload pressure	Burst pressure
RS186A005MV	0-5Bar	6.30±0.05mm	>20Bar	>40Bar
RS186A010MV	0-10Bar	6.30±0.05mm	>30Bar	>50Bar
RS186A016MV	0-16Bar	6.35±0.05mm	>48Bar	>80Bar
RS186A020MV	0-20Bar	6.35±0.05mm	>60Bar	>100Bar
RS186A025MV	0-25Bar	6.45±0.05mm	>75Bar	>125Bar
RS186A035MV	0-35Bar	6.45±0.05mm	>100Bar	>150Bar
RS186A050MV	0-50Bar	6.55±0.05mm	>150Bar	>250Bar
RS186A070MV	0-70Bar	6.65±0.05mm	>200Bar	>300Bar
RS186A100MV	0-100Bar	6.78±0.05mm	>250Bar	>400Bar
RS186A200MV	0-200Bar	6.95±0.05mm	>400Bar	>600Bar
Thickness 18×3.50mm Series
Product model	Working pressure range	Product thickness H	Overload pressure	Burst pressure
RS183A005MV	0-5Bar	3.30±0.05mm	>20Bar	>40Bar
RS183A010MV	0-10Bar	3.30±0.05mm	>30Bar	>50Bar
RS183A016MV	0-16Bar	3.35±0.05mm	>48Bar	>80Bar
RS183A020MV	0-20Bar	3.35±0.05mm	>60Bar	>100Bar
RS183A025MV	0-25Bar	3.45±0.05mm	>75Bar	>125Bar
RS183A035MV	0-35Bar	3.45±0.05mm	>100Bar	>150Bar
RS183A050MV	0-50Bar	3.55±0.05mm	>150Bar	>250Bar
RS183A070MV	0-70Bar	3.65±0.05mm	>200Bar	>300Bar
RS183A100MV	0-100Bar	3.78±0.05mm	>250Bar	>400Bar

High Precision for Accurate Measurements
Both the RS186MV and RS183MV sensors are engineered to deliver exceptional accuracy, making them ideal for applications where precise pressure measurements are critical. These sensors excel as engine oil pressure sensors, manifold absolute pressure sensors, and best tire pressure gauges, ensuring optimal operation of automotive and industrial systems.

Versatile Application Range
These sensors are versatile and can be used across a variety of applications, including water pressure sensors, air compressor sensors, and pressure transmitters for HVAC systems. Their flexibility makes them ideal for automotive diagnostics, industrial machinery, and HVAC maintenance.

Durability and Reliability
The RS186MV and RS183MV sensors are built to withstand harsh environmental conditions. Their durable construction ensures long-lasting performance even in extreme temperatures and moisture-rich environments, making them a reliable choice for both water pressure sensors and pressure transducers.

Manufactured by Leading Pressure Sensor Suppliers
Manufactured by trusted pressure transmitter manufacturers and pressure transducer suppliers, these sensors adhere to the highest standards of quality and performance. They offer unparalleled reliability and are suitable for diverse applications that require accurate pressure monitoring.
