FT601Q-B-T High Speed ADC DAC USB 3.0 To FIFO Interface Bridge Chip USB 2.0
Brand Name:FTDI
Certification:ROSH
Model Number:FT601Q-B-T
Minimum Order Quantity:1
Delivery Time:5-8day
Payment Terms:Western Union,T/T
Contact Now
Add to Cart
Verified Supplier
Location:
Shenzhen China
Address:
Room E, 22nd Floor, Block B, Duhui 100 Building, Huaqiangbei Subdistrict, Futian District, Shenzhen City
Supplier`s last login times:
within 42 hours
Product Details
Company Profile
Product Details
The ultra-high-speed USB 3.0 to FIFO interface bridge chip supports USB 2.0 USB 3.0 FT601Q-B-T
The FT600/FT601 is a USB 3.0 to FIFO interface
bridge chip with the following advanced features:
Supports Remote Wakeup capability.
Supports USB 3.0 Super Speed (5Gbps)/USB
2.0 High Speed (480Mbps)/USB 2.0 Full
Speed (12Mbps) transfer.
Supported
USB
Control/Bulk/Interrupt
Transfer
Up to 8 configurable endpoints (PIPEs).
Type:
Supports 2 parallel slave FIFO bus protocols
245 and FIFO mode, FT601 with 32 bit
parallel interface has a data bursting rate up
to 400MB/s.
Supports 4 IN channels and 4 OUT channels
on FIFO bus connectivity.
Built-in 16kB FIFO data buffer RAM.
Supports multi voltage I/O: 1.8V, 2.5V and 3.3V.
Configurable GPIO support.
Internal LDO 1.0V regulator.
Integrated power-on-reset circuit.
User programmable USB descriptors.
Supports Battery Charging spec. BC1.2 battery charging
detection.
Available as FT600-16bit/FT601-32bit FIFO interface.
Industrial operating temperature range: -40 to 85⁰C.
Available in compact Pb-free QFN-76(32bit) and QFN
56(16bit) packages (both RoHS compliant).
1 Typical Applications
Upgrading Legacy Peripherals to USB
Utilising USB to add system modularity
Interfacing PLD/FPGA based designs to USB 3.0
USB 3.0 data acquisition
1.1 Driver Support
Royalty free D3XX Direct Drivers
(USB Drivers + DLL S/W Interface)
Windows 10
Windows 8
Windows 7
Mac OS-X (available in 2017)
Linux
| 商品目录 | USB转换芯片 | |
| 应用功能 | USB转FIFO | |
| USB协议版本 | - |
| 封装/外壳 | 76-VFQFN 裸露焊盘 |
| 接口 | FIFO |
| 工作温度 | -40°C ~ 85°C |
| 标准 | USB 3.0 |
| 功能 | 桥,USB 至 FIFO |
| 协议 | USB |
| 电流-供电 | - |
| 电压-供电 | 1.65V ~ 3.6V |
Packaging and transportation instructions
- According to the standard export packaging.
Customers can choose from cartons, wooden cases and wooden pallets according to their own requirements.
