Security Monitoring 16 Port Poe Switch 100M 1000M Ethernet Gigabit Switch
Model Number:MSG18CP
Minimum Order Quantity:1
Delivery Time:5-8 week
Payment Terms:T/T
Place of Origin:China
Packaging Details:Wooden box packaging / cardboard box packaging
Contact Now
Add to Cart
Verified Supplier
Location:
Jincheng China
Address:
3rd Floor West of Building 101, Xirui Industrial Park, No. 569 Jincheng 3rd Road, Xi 'an Economic and Technological Development Zone，Xi'an City,China
Supplier`s last login times:
within 42 hours
Product Details
Company Profile
Product Details
16-port Gigabit security monitoring dedicated POE switch
Service
You can have the product replaced within 7 days due to quality
problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.
Specification
Type | MSG18CP |
Port | 10/100/1000M RJ45(PoE):16pcs 10/100/1000M RJ45:2pcs |
Storage and Forwarding | Support |
MAC Address Table | 8K |
POE Power | POE Standard:IEEE 802.3af/at compliant Maximum power supply capacity of the port:30W Maximum power supply capacity of the entire machine:180W |
Operating temperature | 0°C~40°C |
Storage temperature | -40°C~70°C |
Operating humidity | 10% to 90% RH non-condensing |
Storage humidity | 5% to 90% RH non-condensing |
Input Power | 220V~50Hz |
System Module Switch | Standard Exchange;Video Surveillance;VLAN Isolation |
Support Agreement | IEEE 802.3 Ethernet Media Access Control Protocol IEEE 802.3i 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet *IEEE 802.3z 1000BASE-X Gigabit Ethernet (Fiber) IEEE 802.3x Flow Control |
Data transmission rate | Ethernet 10Mbps half-duplex, 20Mbps full-duplex Fast Ethernet 100Mbps half -duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex |
| 10Base-T: 2 pairs of Category 3 (Cat3) or above UTP/STP (≤100m) 100Base-TX: 2 pairs of Category 5 (Cat5) or above UTP/STP (≤100m) 1000Base-T: 4 pairs of Category 5e (Cat5e) or above UTP/STP (≤100m) *1000BASE-SX: 62.5μm/50μm MMF (2m to 550m) *1000BASE-LX: 62.5μm/50μm MMF (2m to 550m) or 10μm SMF (2m to 5000m) |
