| Parameter | Value |
|---|---|
| Frequency Range | 60 Hz - 18 kHz (±3 dB); 50 Hz - 20 kHz (-10 dB) |
| Coverage Angle | Horizontal: 100°; Vertical: 10° (adjustable) |
| Sensitivity | High Frequency (HF): 112 dB; Low Frequency (LF): 103 dB |
| Nominal Power | 350 W |
| Impedance | 16 ohms |
| Sound Pressure Level | HF: 137 dB; LF: 134 dB |
| High Frequency Section | 1x3 inch compression tweeter (可压缩高音扬声器) |
| Low Frequency Section | 1x10 inch woofer (低音扬声器) |
| Dimensions (H×W×D) | 308 mm × 580 mm × 390 mm |
| Weight | 23 kg |
| Connectors | 2 × NL4 |
| Cabinet Material | 15mm and 18mm Baltic birch plywood (波罗的海桦木胶合板) |
| Cabinet Finish | Black polyurethane coating (黑色聚氨酯涂层) |
| Protective Grille | Black, epoxy-coated and acoustically transparent foam (黑色, 带有环氧涂层和声学透明泡沫) |
| Parameter | Value |
|---|---|
| Frequency Range | 40 Hz – 200 Hz (±3 dB) 30 Hz – 320 Hz (-10 dB) |
| Coverage Angle | Omnidirectional |
| Sensitivity | 100 dB SPL (1W/1m) |
| Rated Power | 1000 W |
| Impedance | 8 ohms |
| Max Sound Pressure (SPL) | 136 dB (Peak) |
| Low-Frequency Section | 2×15-inch vented woofers |
| Cabinet Material | 15mm/18mm Baltic birch plywood |
| Cabinet Finish | Black polyurethane coating |
| Protective Grille | Black epoxy-coated, acoustically transparent fabric |
| Dimensions (H×W×D) | 680 × 580 × 790 mm |
| Weight | 60 kg |
Powering the World's Stages Since 2015
As a leading supplier of professional stage equipment, ShowTech
Solutions has more than a decade of expertise in delivering
cutting-edge show technology around the world. Specializing in
demanding environments such as concerts, theaters, and live events,
we offer comprehensive solutions from intelligent lighting and line
array systems to rugged LED displays such as the Guide Visual G10
Series.
With over 15 years of experience, we serve more than 500 clients
across Asia, Europe, and the Americas, from touring productions to
permanent installations in venues such as the Shanghai Grand
Theater and Singapore's Esplanade. Backed by an ISO-certified
technical team, we design reliability into every project--ensuring
seamless execution through rigorous equipment validation and 24/7
global support.
Driven by innovation and backed by proven hardware, we transform
creative visions into unforgettable audience experiences.
