Combination Weigher Packaging Machine with Z-Type Feeder
As a core solution for automated quantitative packaging in various
industries, the combination weigher packaging machine integrated
with a Z-type feeder realizes a seamless connection between
material conveying and precision weighing-packaging. This
integrated system significantly improves production efficiency,
ensures weighing accuracy, and reduces material waste, making it an
indispensable equipment for modern manufacturing enterprises.
Combination Weigher Packaging Machine: Precision and Efficiency Redefined
The combination weigher, also known as a multihead computer
combination weigher, is an advanced automatic quantitative weighing
device powered by intelligent computer algorithms. Unlike
traditional single-hopper weighing equipment, it features multiple
independent weighing hoppers operating simultaneously, achieving
rapid and precise weight matching through high-speed data analysis.
Core Working Principle
The workflow of the combination weigher is highly automated and
efficient. First, materials are evenly distributed to each feeding
hopper via a vibrating feeder. Each weighing hopper then
independently measures the material weight and transmits real-time
data to the central control system. The integrated PLC control
system quickly calculates all possible weight combinations and
selects the one closest to the target weight, ensuring consistent
packaging quality. Finally, the qualified material combination is
discharged into the packaging unit to complete bag making, sealing,
date coding, and counting in one go.
Key Features
- High Precision & Efficiency: Equipped with high-resolution load cells, the weighing accuracy ranges from ±0.1g to ±1g, meeting strict quality control requirements. The maximum packaging speed can reach 120 bags per minute, significantly outperforming manual weighing and traditional equipment.
- Intelligent Operation: Adopting a full-computer touch screen man-machine interface, the operation is simple and intuitive. The internationally renowned brand PLC control system and imported electrical components ensure stable performance and reliable operation, with automatic fault alarm functions to minimize downtime.
- Versatile Adaptability: Suitable for granular, blocky, spherical, and irregular materials such as nuts, candies, puffed foods, frozen foods, pet food, and seeds. It supports various bag types including pillow bags, gusset bags, and side seal bags, compatible with heat-sealable composite materials like polyester/polyethylene and aluminum foil composites.
- Modular Design: The open-frame construction and tool-less adjustable components facilitate easy cleaning, maintenance, and material changeover. It can be customized with optional devices such as nitrogen charging systems, anti-static devices, and vacuum sealing units according to customer needs.
Z-Type Feeder: Efficient and Gentle Material Conveying
The Z-type feeder (also known as Z-type bucket elevator) is a
high-performance conveying equipment perfectly matched with the
combination weigher. It integrates horizontal and vertical
conveying into one unit, replacing the need for multiple separate
conveying devices and optimizing workshop space utilization.
Working Principle
Materials are fed into the hoppers from the inlet, lifted
vertically by the chain-driven hoppers to the top of the machine,
and then flipped downward to discharge into the receiving trough.
The entire conveying process is completed in a closed casing,
ensuring no material leakage or dust emission. The lower part is
equipped with a counterweight lever tensioning device that
maintains constant tension automatically, preventing chain slipping
or disengagement.
Features
1.Chinese and English touch screen display, intuitive and simple
operation
2.Plc computer control system, the operation is more stable, and
any parameter can be adjusted without stopping the machine
3.An groups of parameters can be stored, and the replacement of
varieties is more accurate
4.The servo motor is used to pull and touch, and the positioning is
more accurate
5.The packaging styles are diversified, such as back sealing,
gusseting, connected bag, punching, etc.
6.The production of bag making, sealing, packaging, and date
printing is completed at one time.
7.Servo fim feeding system, horizontal sealing pneumatic contro,
accurate positioning, excelent perfommance of the whole
madhine Maximizing the reliability and high degree of intelligence
8.The cleaning function can keep the hopper in the open state,
which is convenient for daily cleaningand maintenance
9.lP65 waterproof and dust-proof design
10.The ropening angle of the motor can be set arbitrarily according
to the material characteristics
