Samkoon PRO/MAX Series EtherCAT Bus PLC with 32-Axis Motion Control
High Performance Controller and EtherCAT Master
High-performance industrial controller combining EtherCAT master
functionality with advanced motion control capabilities for
precision automation applications.
Core Specifications
| CPU | 1GHz frequency + large-scale FPGA logic |
|---|---|
| Operating System | Linux Multitasking |
| Memory | 512MB RAM + 4GB eMMC FLASH |
| Storage | Full register area power-down retention |
| EtherCAT Interface | 1x EtherCAT Master, supports up to 32 axes |
| Local I/O | 16 high-speed inputs & 16 high-speed outputs (supports 8 local axes with 200kHz) |
| Power Supply | DC 24V ±15%, Power consumption: 10W |
| Dimensions | 92.5 * 105 * 98 mm |
| Environment | Temp: 0°C ~ 50°C, Humidity: 5~95% RH (non-condensing) |
PRO Series Key Features
- Built-in 32-point IO with local 8-axis high-speed pulse output and 16-channel high-speed counting
- EtherCAT nanosecond real-time network master protocol stack with minimum system cycle of 500μs
- Multiple debugging interfaces: USB, U disk, Ethernet, RS485
- PLC axis control parameterized configuration with online debugging
- IEC61131-3 compliant ladder diagram-based motion control MC instructions
- Mapping programming for large-scale hardware configuration
- Electronic gear, multi-axis interpolation, and electronic cam functions
MAX Series Enhanced Capabilities
- Secondary development with open register, compiled PLC, and G-code programming
- Spatial straight lines, circular arcs, spirals, spline curves, and NURBS curve interpolation
- Smooth trajectory speed transition with continuous small line segment G64 interpolation
- Pitch error compensation, backlash compensation, and tool radius compensation
- Axis parameterized configuration management, task management, and alarm management
- Z pulse return to zero and secondary return to zero modes
- Variable speed during movement, multiplier settings, start/pause functions
- G-code 3D trajectory, ladder offline and online simulation
- CAD, text, and picture import to generate G-code functionality
Communication Interfaces
Multiple debugging and communication interfaces including Ethernet,
USB, U-disk, and dual RS485 ports supporting Modbus TCP/RTU and
custom protocols for seamless connectivity.
High-Speed I/O & Pulse Control
Equipped with 16 high-speed inputs and 16 high-speed outputs,
supporting up to 8 local axes with 200kHz high-speed pulse output
and 16-channel high-speed counting for real-time precision control.
EtherCAT Real-Time Performance
Built-in EtherCAT master stack ensures nanosecond-level
synchronization with minimum system scan cycle of 500μs, supporting
up to 32 motion axes via high-speed industrial bus.
Motion Control Standards
IEC61131-3 compliant motion control instruction sets including
point control, homing, interpolation, electronic cam, and more.
Motion parameters can be configured and debugged online.
Product Naming Convention
PRO: PRO series PLC | MAX: MAX series PLC
C: Host CPU module | E: Expansion Module
16X16T: 16 inputs and 16 outputs | 16X: 16 inputs
16T: 16 outputs | 8X8T: 8 inputs and 8 outputs
8E8T: 8-way encoder, 8-way output | START: Network expansion module start
END: Network expansion module end | 4AI: 4 analog inputs
4AO: 4 analog outputs | 4PT: 4-way temperature measurement
A: Version number
C: Host CPU module | E: Expansion Module
16X16T: 16 inputs and 16 outputs | 16X: 16 inputs
16T: 16 outputs | 8X8T: 8 inputs and 8 outputs
8E8T: 8-way encoder, 8-way output | START: Network expansion module start
END: Network expansion module end | 4AI: 4 analog inputs
4AO: 4 analog outputs | 4PT: 4-way temperature measurement
A: Version number
Detailed Specifications Comparison
| Model | PRO-C 16X16T A | MAX-C 16X16T A |
|---|---|---|
| CPU | 1GHz frequency + large-scale FPGA logic | |
| Operating System | Linux Multitasking | |
| RAM Space | 512MBytes | |
| FLASH Space | 4GBytes eMMC | |
| Power-down Storage | Full register area power-down retention | |
| EtherCAT | 1x EtherCAT master, max. 32 axes | |
| Ethernet | 2 channels, Modbus TCP protocol | |
| RS485 | 2 channels, Modbus/Freeport protocol | |
| I/O | 16 high-speed inputs & outputs, 8 local axes with 200KHz | |
| MC Interpolation | 8-channel 4-axis linear/circular | 8-channel 9-axis G-code interpolation |
| G-code Function | -- | Advanced G-code with macro B support |
| Continuous Interpolation | -- | G64 continuous small line segment |
| File Function | -- | G-code file download and U-disk support |
| Debugging Function | -- | 3D trajectory simulation, CAD import |
Expansion Modules
Digital I/O Expansion Modules
| Model | PRO-E-16X16T | PRO-E-16X | PRO-E-16T | PRO-E-8X8T |
|---|---|---|---|---|
| Input Channels | 16 | 16 | / | 8 |
| Output Channels | 16 | / | 16 | 8 |
| Input Rate | 10KHz | 10KHz | / | 200KHz |
| Output Rate | 10KHz | / | 10KHz | 200KHz |
| Output Load Current | 0.6A per channel | / | 0.6A per channel | 0.6A per channel |
Analog Expansion Modules
| Model | PRO-E-4AI | PRO-E-4AO |
|---|---|---|
| Input Channels | 4 | / |
| Output Channels | / | 4 |
| Input Current | 0-20mA | / |
| Output Current | / | 0-20mA |
| Input Voltage | ±10V, ±5V | / |
| Output Voltage | / | ±10V, ±5V |
| Resolution/Accuracy | 16 bit/±0.2% | 12 bit/±0.2% |
Temperature Expansion Module
| Model | PRO-E-4PT |
|---|---|
| Input Channels | 4 channels |
| Sensor Type | P-type/K-type thermocouple, PT100 |
| Resolution/Accuracy | 24位/±0.2% |
Key Advantages
High-Performance Architecture
1GHz CPU with FPGA logic for superior processing power
Nanosecond Real-Time Control
EtherCAT master with 500μs cycle for precision timing
Versatile Development Options
Multiple programming methods including ladder, G-code, and compiled
PLC
Advanced Motion Interpolation
Complex trajectory control with spatial curves and NURBS
interpolation
Comprehensive Simulation
3D trajectory simulation and CAD import for efficient development
Certifications & Quality
CE, CCC, ISO international certifications and domestic honors
ensuring quality and compliance with global standards.
Packaging & Delivery
Secure wooden case packaging with professional handling for
international shipping.
