Four Quadrant Variable Frequency Drive High Efficiency VFD Customizable
Brand Name:LAEG
Certification:CE
Model Number:LD320-5R5G-T4B
Minimum Order Quantity:1
Delivery Time:15days
Payment Terms:L/C,T/T
Contact Now
Add to Cart
Verified Supplier
Location:
Shenzhen Guangdong China
Address:
Room 508, 5th Floor, Huajian Building, No. 473 Guangshen Road (Shajing Section), Xinqiao Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong Province, China.
Supplier`s last login times:
within 33 hours
Product Details
Company Profile
Product Details
Ld320 High-Efficiency Inverter Delivering Smooth Torque Control
with Excellent Dynamic Response
Delivering smooth torque control with excellent dynamic response
for industrial applications.
Product Overview
| Model Number | LD320-5R5G-T4B |
|---|---|
| Working Principle | Vector Control Transducer |
| Switch Mode | PWM Control |
| Main Circuit Type | Current |
| Power Supply Voltage | Low Voltage Variable-Frequency Drive |
| Transformation Link | AC-DC-AC Variable-Frequency Drive |
| DC Power Nature | Current Variable-Frequency Drive |
| Function Type | Simple Type |
| Brand | Laeg |
| Protection Degree | IP55/65 |
| Voltage | 380V, or Customized |
| Frequency | 50Hz, 60Hz |
| Output Frequency | 0.01-400 Hz |
| Transport Package | Wooden Cases |
| Specification | 12*9*9 cm |
| Trademark | LAEG |
| Origin | Anhui China |
| HS Code | 8504400090 |
| Production Capacity | 5000/Months |
Manufacturer Profile
With over 55 years of construction and development, Lu'an Jianghuai
Motor has become the largest industrialized enterprise in the
small, medium and large motor industry, offering the most complete
product series and comprehensive service network. Our product range
includes various high-efficiency and energy-saving
low-voltage/high-voltage motors, DC motors, high-efficiency
explosion-proof motors, special motors, permanent magnet motors,
and other synchronous/asynchronous motors. Applications span power
stations, metallurgy, steel, sugar making, coal mining, machinery,
petroleum, chemical engineering, water conservancy, cement,
papermaking, environmental protection, and pharmaceuticals. ANHUI
LAEG, a branch of Luan Jianghuai Motor Company, specializes in VFD
production with over 20 years of expertise.
Key Advantages
- Compact Design: Advanced modular design saves over 30% volume compared to same-power inverters, offering flexible installation options
- Enhanced Excitation Performance: Automatically adjusts motor excitation current to improve efficiency and save energy during light loads
- Multiple Display Options: Choose between digital or LCD operation panels for clear parameter visualization and convenient maintenance
- Universal Drive Compatibility: Operates three-phase asynchronous motors, permanent magnet synchronous motors, and servo motors in sensorless mode for optimal energy savings
- High Reliability: Features long-life fans, capacitors, and thicker substrate coatings for enhanced durability and resistance, meeting ROHS environmental standards and CE certification
Technical Specifications
| Model | AD10-4R0G-T4-B |
|---|---|
| Adapt Motor Power | 4kW / 5HP |
| Rated Output Capacity | 5.9 kVA |
| Rated Output Current | 9A |
| Output Frequency | 0.01-400 Hz |
| Carrier Frequency Range | 1-16 kHz |
| Overload Capacity | 150% rated current for 60s, 200% rated current for 3s |
| Input Current | 10.5A |
| Input Voltage & Frequency | 3 phase 380V, 50-60Hz |
| Voltage Range | 315V-450V |
| Cooling System | Forced cold air |
| Brake Unit | Built-in |
Input Voltage Specifications
| Input Voltage Frequency | Model | Input Current (A) | Motor Power (kW) | Motor Horsepower (HP) | Rated Output Capacity (kVA) | Output Current (A) | Output Frequency | Carrier Frequency |
|---|---|---|---|---|---|---|---|---|
| 1AC 220V 50/60Hz | AD10-0R7G-S2B | 8.2 | 0.75 | 1 | 1.5 | 4 | 0.1-400Hz | 1-16kHz |
| AD10-1R5G-S2B | 14 | 1.5 | 2 | 3 | 7 | 0.1-400Hz | 1-16kHz | |
| AD10-2R2G-S2B | 23 | 2.2 | 3 | 4 | 9.6 | 0.1-400Hz | 1-16kHz | |
| 3AC 380V 50/60Hz | AD10-0R7G-T4B | 3.4 | 0.75 | 1 | 1.5 | 2.1 | 0.1-400Hz | 1-16kHz |
| AD10-1R5G-T4B | 5 | 1.5 | 2 | 3 | 3.8 | 0.1-400Hz | 1-16kHz | |
| AD10-2R2G-T4B | 5.8 | 2.2 | 3 | 4 | 5.1 | 0.1-400Hz | 1-16kHz | |
| AD10-4R0G-T4B | 10.5 | 3.7 | 5 | 5.9 | 9 | 0.1-400Hz | 1-16kHz | |
| AD10-5R5G-T4B | 14.6 | 5.5 | 7.5 | 8.9 | 13 | 0.1-400Hz | 1-16kHz | |
| AD10-7R5G-T4B | 20.5 | 7.5 | 10 | 11 | 17 | 0.1-400Hz | 1-16kHz | |
| AD10-011G-T4B | 26 | 11 | 15 | 17 | 25 | 0.1-400Hz | 1-16kHz |
Application Areas
Manufacturing Facility
Our motor factory scale and product line, products details
Certifications
We hold CE, ISO9001, CCC and other certifications
Packaging
Frequently Asked Questions
Are you a factory or trading company?
LU'AN JIANGHUAI is a factory that has been focusing on motors and
accessories for more than 50 years.
What about the warranty?
We offer 12 month warranty period as the quality guarantee.
Can you do OEM?
Yes, we offer OEM services.
How about your service?
We provide comprehensive pre-sale, in-sale, and after-sale service.
Our principle is customer first, focusing on long-term cooperation.
What are your terms of delivery?
Generally we ship FOB, but we can accommodate CNF, CIF, and DDP
terms based on your requirements.
What's the delivery time?
15 to 35 days after receiving your payment in advance.
