Universal Microcontroller Development Experiment Box
Product Overview
This comprehensive microcontroller development trainer serves as an
ideal experimental companion for courses including "MCS-51
Microcontroller Principles and Interfaces," "Microcontroller
Control Technology," "Automation Control," and "EDA." Designed with
compact dimensions, multifunctionality, and easy expansion
capabilities, the system provides an excellent development
environment for teaching experiments, course design, graduation
projects, and research applications.
Key Features
Complete Teaching Platform: Designed specifically for MCS-51 microcontroller principles,
single-chip control technology, and EDA courses. Suitable for
classroom teaching, course design, graduation projects, and R&D
debugging in universities and vocational colleges.
Comprehensive Hardware Resources: Equipped with AT89S52 main CPU, large-capacity program and data
memory. Pre-integrated LCD display, matrix keyboard, LED
dot-matrix, digital tube, classic interface chips, stepper/DC
motor, DS18B20 temperature sensor, pressure sensor, relay, buzzer,
RS232/485 interfaces, ISP download, and serial communication
interfaces.
Advanced Simulation & Multi-chip Support: Includes 51-series emulator supporting Keil-C debugging with
single-step and break-point functions. Emulator operates
independently without occupying CPU resources. Optional modules
support C8051F, AVR ATMEGA16, and EDA development.
Open Architecture for Development: Full lead-out of address bus, data bus, and control bus. Reserved
expansion interfaces support custom experiments and optional
external functional modules.
Dual Operating Modes: PC-linked debugging via software or offline operation. Automatic
switching to offline status without emulator, directly running
built-in experimental programs. Supports Assembly and C51 compiling
and debugging with ISP in-system programming.
Robust Mechanical Design: Lightweight aluminum alloy chassis with fire-proof insulation
material. Gold-plated locking sockets ensure reliable contact.
Built-in high-performance DC regulated power supply for convenient
wiring.
Extensive Experiment Library: Comprehensive coverage of software programming, I/O control, AD/DA
conversion, motor driving, sensor acquisition, dot-matrix and LCD
display, serial communication, and dozens of hardware-software
integrated experiments.
Hardware Experiment Projects
P1 port light-on experiment
P1 port turn signal experiment
P3.3 port input, P1 port output experiment
Industrial sequence control experiment
8255 A, B, C port output square wave experiment
8255 PA port controls PB port
8255 controls traffic lights
Simple I/O expansion experiment
A/D0809 conversion experiment
D/A0832 conversion experiment
8279 keyboard display experiment
General printer experiment (printer optional)
Micro printer print character, curve, Chinese character experiment
(printer optional)
I2C memory card read and write experiment
Relay control experiment
Stepper motor control
8253 square wave experiment
