Smartphone Automatic Drop Testing Machine Repeated Micro Drop Testing Machine Electronic Components Durability Tester
Brand Name:HUAKAI
Minimum Order Quantity:1 piece
Voltage:220 V
Protection Class:IP65
Type:Testing Machine
Application:Drop Testing
Contact Now
Add to Cart
Verified Supplier
Address:
23.120050092731365, 113.80487611226312
Supplier`s last login times:
within 22 hours
Product Details
Company Profile
Product Details
Product Overview
HK-617 electronic micro drop testing machine is designed for
repeated drop testing of small consumer electronic products such as
mobile phones, telephone handsets, interphones, MP3, CD and electronic dictionaries. The equipment simulates repeated drop
conditions to evaluate product impact resistance and durability performance.
Functions & Applications
* Mobile phone durability testing
* Consumer electronic product drop testing
* Product impact resistance evaluation
* Reliability testing for small electronic devices
* Quality inspection testing for electronic products
mobile phones, telephone handsets, interphones, MP3, CD and electronic dictionaries. The equipment simulates repeated drop
conditions to evaluate product impact resistance and durability performance.
Functions & Applications
* Mobile phone durability testing
* Consumer electronic product drop testing
* Product impact resistance evaluation
* Reliability testing for small electronic devices
* Quality inspection testing for electronic products
Product Paramenters
Item | Specification | ||||||
Model | HK-617 | ||||||
Test stations | 5 stations (independent control) | ||||||
Test capacity | 5 samples simultaneously | ||||||
Maximum specimen weight | 2kg | ||||||
Drop height | 60-250mm | ||||||
Test speed | 6-30 cycles/min | ||||||
Control system | PLC controller with touch screen | ||||||
Drop test type | Six faces drop test | ||||||
Air supply | ≥0.6MPa | ||||||
Power supply | AC220V or specified | ||||||
Machine weight | Approx 260kg | ||||||
Machine size | According to final design drawing | ||||||
Products Description
Structure & System Configuration
* Pneumatic cylinder lifting mechanism
* Adjustable mechanical fingers for specimen holding
* PLC programmable control system
* Touch screen operation interface
* Independent counting system
* Automatic stop after preset test cycles
* Integrated electrical structure design
Standards
Designed according to general electronic product drop testing requirements and reliability testing practices.
* Pneumatic cylinder lifting mechanism
* Adjustable mechanical fingers for specimen holding
* PLC programmable control system
* Touch screen operation interface
* Independent counting system
* Automatic stop after preset test cycles
* Integrated electrical structure design
Standards
Designed according to general electronic product drop testing requirements and reliability testing practices.
Details Images
Certifications
Company Profile
Product packaging
Packaging & Shipping
• Internal Protection: Anti-collision foam padding and
moisture-proof wrapping are applied to prevent mechanical damage
and corrosion during transit. • Marking & Labeling: Each package is
clearly labeled with model number, dimensions, weight, and handling
instructions for easy identification. • Loading: All packages are
reinforced and suitable for forklift handling and container
loading.
• Shipping Options: By sea, air, or express courier according to
customer preference.
