Worldia ISO standard In stock and fast delivery Milling Tools PCD inserts for milling non-ferrous finishing materials
Brand Name:Worldia
Model Number:BEHW PCD tipped Milling Inserts
Minimum Order Quantity:1
Delivery Time:5-15
Place of Origin:Beijing
Packaging Details:Blue Boxes
Contact Now
Add to Cart
Verified Supplier
Location:
Beijing Beijing China
Address:
Room H-02, 5F, M7 Building, No.1 Jiuxianqiao East Road, Chaoyang District, Beijing, China 100015
Supplier`s last login times:
within 45 hours
Product Details
Company Profile
Product Details
Design Feature:
Applications:
BEHW PCD-tipped Milling Inserts for Light and Medium Applications PCD-tipped milling inserts with various angles, wipers and corner radii for face and shoulder milling applications with higher depth of cut and Si-content ≤10%.BEHW PCD-tipped Milling Inserts for Heavy-Duty ApplicationsPCD-tipped milling inserts with various angles, wipers and corner radii for face and shoulder milling applications with higher depth of cut and Si-content ≥10%.BEHW PCBN-tipped Milling Inserts for Face and Shoulder Milling ApplicationsPCBN-tipped milling inserts with various angles, wipers and corner radii for face and shoulder milling applications of cast iron and hardened materials with a higher depth of cut.SDHN Full-Face PCBN Milling Inserts for Finish Face Milling ApplicationsPCBN full-face milling inserts with various angles and wipers for finish face milling of cast iron and hardened materials.
Technical Parameters:
| Product Name: | BEHW PCD Tipped Milling Inserts |
| Machine Type: | Face + Shoulder Milling |
| Cutting Material: | PCD |
| Cutting Edges: | 6 |
| Standard Cutter Diameter (mm): | 25 - 40 Mm Or Above 40 Mm |
| Max. DOC/ Ap (mm): | 4 |
| max RPM: | 40000 |
| Customized support: | OEM, ODM, OBM |
| Place of Origin: | Beijing |
| MOQ: | 10 PCS |
Specification:
BEHW PCD-tipped Milling Inserts for Light and Medium Applications
BEHW PCD-tipped Milling Inserts for Heavy Duty Applications
PCD Grades and Application Recommendations
:
Workpiece | Grade | Grain size (μm) | Characteristics | Application |
Mater N ial | PD10E | 10 | PD10E is the universal grade in the market. It’s the first choice for many applications where a good balance of toughness and wear resistance are required. | This grade is commonly used for non-ferrous finishing applications. Other successful applications include machining of wood, MDF, low-medium content silicon aluminum alloys, carbide, hard rubber, graphite and so on. |
PD32E | 2~30 | PD32E has a unique combination of wear resistance, edge strength and edge quality. It contains a carefully selected mix of microns diamond (between 2 - 30 µm). The combination of these particle sizes and a specifically developed high-pressure sintering process produces a structure with extreme abrasion resistance and good thermal stability. | Application areas include the machining of abrasive workpieces such as MMC, high silicon aluminum alloys as well as machining of carbide, hard rubber, graphite and other materials. |
FAQ:
Q1: What is the brand name of the Face Milling Cutters product?
A1: The brand name of the Face Milling Cutters product is Worldia.
Q2: What is the model number of the product?
A2: The model number of the product is BEHW PCD tipped Milling Inserts.
Q3: Where is the product made?
A3: The product is made in Beijing, China.
Q4: What is the minimum order quantity for the product?
A4: The minimum order quantity for the product is 1.
Q5: What is the packaging details for the product?
A5: The packaging details for the product is blue boxes.
Q6: What is the delivery time for the product?
A6: The delivery time for the product is 5-15 days.
Q7: What is the supply ability for the product?
A7: The supply ability for the product is 20000.
