Bag Milk Packaging Machine Liquid Paste Multi-function Packaging Machine

Brand Name:ZCHONE PACK
Certification:ISO,CE
Model Number:ZC-200
Minimum Order Quantity:1set
Delivery Time:15 work days
Payment Terms:L/C, D/A, D/P, T/T, Western Union, MoneyGram
Contact Now

Add to Cart

Verified Supplier
Location: Foshan Guangdong China
Address: No. 13, Xingye 5th Road, Yundonghai Street, Sanshui District, Foshan City, Guangdong Province
Supplier`s last login times: within 34 hours
Product Details Company Profile
Product Details

Bag milk Packaging Machine Liquid Paste Multi-function Packaging Machine


Bag milk packaging machines are equipment used to automatically package milk bag products. These devices are usually used on production lines and can automatically complete functions such as filling, sealing, date printing, etc. This machine can greatly improve production efficiency and ensure the quality and hygiene standards of product packaging.


Common bag milk packaging machines usually include the following key features:


Automatic control system, which is used to monitor and adjust the packaging process.


Filling system, which can accurately control the filling amount of milk.


Sealing system, which is used to seal the packaging bag.


Date printing system, which can print the production date and other necessary information on the package.


Safety system, which ensures the safety of operators and avoids accidents.


These devices usually differ according to different production needs, and the appropriate bag milk packaging machine can be selected according to the scale of the production line and packaging requirements.


Machine Specification:


ItemZC-X8200ZC-X8250ZC-X8300
Packing speedMAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc.
Bag size(L)100-300mm (W)70-200mm(L)100-350mm (W)130-250mm(L)150-450mm (W)200-300mm
Bag typePre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag
Weighing range10g-1kg10g-2kg10g-3kg

Measurement

accuracy

*≤±0.5~1%, depending on the measuring equipment & materials.
Maximum bag width200mm250mm300mm
Gas consumption0.8Mpa 0.3m3/min (Supply by user)
Total Powder/Voltage2.5KW 380V 50/60Hz2.5KW 380V 50/60Hz3.7KW 380V 50/60Hz
Air compressorNot less than 1CBM
DimensionL1900*W1400*H1450L1900*W1400*H1450L2000*W1500*H1550
Machine Weight1300kg1400kg1500kg
Work flowGiving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products.

(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)




Scope of application of pet food bag packing machine: dog food, cat food, rabbit food, pet freeze-dried, dried small fish, yogurt cubes, etc.


Applicable bag quality: PE composite film, aluminum foil film, aluminized film and other composite material films.


Applicable bag types: stand-up bags, zipper bags, slanted-mouth stand-up bags, flat bags (three-side sealing, four-side sealing, handbag, back-sealing bag, hemming bag, etc.)
