AS5145A-HSSM Sensor IC 12-Bit Programmable Magnetic Rotary Encoder SSOP-16

AS5145A-HSSM Sensor IC 12-Bit Programmable Magnetic Rotary Encoder SSOP-16

Product Description Of AS5145A-HSSM
AS5145A-HSSM is a contact less magnetic rotary encoder for accurate angular measurement over a full turn of 360 degrees.
It is a system-on-chip, combining integrated Hall elements, analog front end and digital signal processing in a single device.
To measure the angle, only a simple two-pole magnet, rotating over the center of the chip, is required. The magnet can be placed above or below the IC.

Specifications Of AS5145A-HSSM

Features Of AS5145A-HSSM
Contact less high resolution rotational position encoding over a full turn of 360 degrees
Two digital 12-bit absolute outputs:
- Serial interface
- Pulse width modulated (PWM) output
Three incremental outputs
Quadrature A/B/I (10 or 12 bit) and Index output signal (preprogrammed versions available AS5145A for 10-bit and AS5145B for 12-bit)
User programmable zero position
Failure detection mode for magnet placement, monitoring, and loss of power supply
Red-Yellow-Green indicators display placement of magnet in Zaxis
Serial read-out of multiple interconnected AS5145 devices using Daisy Chain mode
Tolerant to magnet misalignment and gap variations
Wide temperature range: - 40ºC to +150ºC
Fully automotive qualified to AEC-Q100, grade 0
Small Pb-free package: SSOP 16 (5.3mm x 6.2mm)

Applications Of AS5145A-HSSM
The device is ideal for industrial applications like contactless rotary position sensing and robotics; automotive applications like steering wheel position sensing, transmission gearbox encoder, head light position control, torque sensing, valve position sensing and replacement of high end potentiometers.
