100KV IEC 60243-1 Power Frequencies Electrical Strength Testing Equipment
Application:
This tester is suitable for measuring the breakdown strength and
withstand voltage time of solid insulating materials such as
plastic, film, resin, mica, ceramics, silica gel, glass, insulating
paint, etc. in air or liquid medium, it can measure the breakdown
strength and withstand voltage time under power frequency (48 ~
62Hz) or corresponding DC voltage.
Standards:
IEC60243-1
IEC60243-2
Specifications:
| Breakdown voltage | 0~50kV |
| Booting speed | 100,200,500,1000,2000,5000(KV/S) |
| Voltage measurement accuracy | ≤ 2％ |
| The leakage current selection | 1~100 mA |
| Methods of test | DC & AC |
| Supply power | AC220V 50/60Hz |
| Dimension | L 1400* W 1040* H 1500 mm |
| Weight | 200kg |
1. Booting speed control: Electrical automatic control
2. Methods of booting: Automatic program-controlled
3. Power Frequency: sine wave 50Hz/60HZ
4. Transformer capacity: 10 KVA
5. AC 0~50 KV (continuously adjustable)
