Vertical Hydraulic Section Bending Machine Complicated Structure Full Function

Vertical Hydraulic Section Bending Machine Complicated Structure Full Function

Brand Name:SMART CNC
Certification:CE ISO TUV
Model Number:W24-16
Minimum Order Quantity:1 Set
Delivery Time:45days
Place of Origin:China
Contact Now

Add to Cart

Verified Supplier
Address: No.77 Huicheng Road,Huishan District, Jiangsu Province,214151,China
Supplier`s last login times: within 48 hours
Shipping
lt's easy to get a shipping quote! Just click the button below and complete the short form.
Get Shipping Quote
Product Details Company Profile
Product Details
W24S-16 CNC Hydraulic Section bending machine/ Vertical Section Aluminum Profile Bending Machine

Specification:


Colour:blue


Automatic:Hydraulic


Hydraulic angle rolling machine & section bender

Bend type:stainless steel,angle steel,steel bar,flat steel,channel steel,steel tubes&pipes


Power system:hydraulic


Hydraulic angle rolling machine & section bending machine

1. Perfectly complete pre-bending,rolled-up,roll calibrate.


2. Working principle: two down rollers as main driving roller,or all three rollers as main driving roller,with upper roller fixed and two down rollers do up-and-town movement around one fixed center


3. Well hydraulic control,displacement liquid-crystal display with accuracy+_0.1mm


4. The two touch steel stick can permit the good finishing quality of asymmetric plate section bending


5. Advanced and compact structure with full function.


6. The machine has two oil tanks,and the head can turn over horizontally or vertically.


7. The yield strength bended profile with 320 Mpa (Max).


8. Full function,complicated structure,high precision and very stronger.


Model

Technical Parameters

W24S-16
Max. Anti-Winding Cass-Section Moulds (cm3)16
Winding Speed (m/min)3
Yield Strength (MPa)245

Angle Steel

Internal Winding

Max. Cross – Section(mm)70×8
Min. Winding Dia. (mm)1000
Min. Cross - Section(mm)30×3
Min. Winding Dia. (mm)550

Angle Steel

Eternal Winding

Max. Cross – Section(mm)75×10
Min. Winding Dia. (mm)1000
Min. Cross - Section(mm)30×3
Min. Winding Dia. (mm)550

Channel Steel

Eternal Winding

Model12
Min. Winding Dia.800

Channel Steel

Internal Winding

Model14
Min. Winding Dia.900

Flat Steel

plane-bending

Max. Cross - Section150×25
Min. Winding Dia.700

Flat Steel

vertical bending

Max. Cross - Section75×16
Min. Winding Dia.760
Motor PowerKW

5.5



China Vertical Hydraulic Section Bending Machine Complicated Structure Full Function supplier
