PES Membrane Rplacement 20 Filter Cartridge
General Description
The PES filter element is made of imported hydrophilic asymmetric PES membrane and imported non-woven fabric and mesh as the support layers. Its asymmetric membrane structure enables the filter to greatly extend the service life of the filter while ensuring the filtration efficiency, thereby effectively saving the filtration cost of the system. They are produced in clean room, 100% integrity tested and flushed with high purity water. Suitable for ultra-pure water filtration, circulating cleaning filtration, high pressure water filtration and aqueous acid/alkaline chemical filtration in liquid crystal display manufacturing processes.
Dimensions
| Outer Diameter | 2.7" (69mm) |
| Length | 5'', 10", 20", 30", 40" |
Material of Constructions
| Filter Medium | PES |
| Support layer | PP |
| Cage/Core/End cap | PP |
| Seal Material | Silicone, EPDM, NBR, Viton, Teflon, E-fkm |
Performance
| Removal rating | 0.1μm, 0.22μm, 0.45μm, 0.65μm,1.2μm |
| Max. operating temperature | 80℃ |
| Max. operating pressure | 4.2 Bar @ 21℃ |
Max. operating pressure (Reverse Direction) | 2.4 Bar @ 80℃ |
| Max. temperature sterilization | 20 times, 30minutes cycles at 121℃ |
Products Display
Application
Sterilization filtration of large infusion (LVP), small injection (SVP), WFI water for injection
Buffer filtration
Sterilization filtration of cleaning solution and disinfectant
Sterilization filtration of eye drops
Sterilization filtration of biological products
Sterilization of beer, wine, beverages, etc.
Features
1. Excellent performance of chemical compatibility;
2. Hydrophilic membrane with high flow;
3. Non-fiber releasing according to pharmaceutics and food industry requirements;
4. Experiencing 100% integrity tested;
5. Flushed with ultrapure water;
