Round Common Cathode 7-Segment LED Temperature Display Controller
Brand Name:LIGHT-BO
Certification:ISO9001&RoHS
Model Number:LB-RC41LUR1S
Minimum Order Quantity:1000
Delivery Time:15-20days
Payment Terms:TT in advance
Contact Now
Add to Cart
Verified Supplier
Location:
Shenzhen Guangdong China
Address:
ROOM 308,3/F,BUILDING 1,BAIWANG RESEARCH AND DEVELOPMENT BUILDING,NO. 5298 ,SHAHE WEST ROAD,XILI STREET,NANSHAN DISTRICT,SHENZHEN
Supplier`s last login times:
within 1 hours
Product Details
Company Profile
Product Details
Round Common Cathode 7-Segment LED Temperature Display Controller
Code:Super Bright Red -R
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 | 2.2 | V | |
| Reverse Voltage | Vr | Ir=10uA | 5 | V | ||
| Luminous Intensty | Iv | If=10mA | 50 | 60 | mcd | |
| Spectrum With Of Half Value | △λ | If=10mA | 20 | nm | ||
| Wavelength | Dλ | If=10mA | 630 | 635 | nm |
Code:Ultra Bright Red -UR
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 | 2.2 | V | |
| Reverse Voltage | Vr | Ir=10uA | 5 | V | ||
| Luminous Intensty | Iv | If=10mA | 90 | 100 | mcd | |
| Spectrum With Of Half Value | △λ | If=10mA | 20 | nm | ||
| Wavelength | Dλ | If=10mA | 620 | 625 | nm |
Absolute Maximum Ratings(Ta=25℃)
| Parameter | Symbol | Ratings | Unit |
| Forward Current(per dice) | Ipm | 20 | mA |
| Reverse Voltage(per dice) | Vr | 5 | V |
| Power Dissipation(per dice) | Pm | 80 | mW |
| Operating Temperature Range | Topr | -40~+120 | ℃ |
| Storage Temperature Range | Tstg | -40~+120 | ℃ |
| Solder Temperature(3 sec) | Th | 260 | ℃ |
Feature of Segment LED Displays
-- White segment Black surface
-- High luminous intensity
-- Low current operation
-- Stable performance
-- Continuous uniform segments
-- Easy mounting on PCB
-- IC compatible
-- RoHS compliant
Application of Segment LED Displays
-- Audio Equipment or instrument panels;
-- General using for digital indicators;
-- Multimedia products;
-- Bank exchange rate display;
-- LED clock display;
-- Display for gas station and other various display areas of equipment/machine.
Industrial Equipment
Industrial ovens, reliability test equipment, analytical instruments, process control equipment, test and measuring instruments, temperature controllers, programmable logic controllers, security systems
FAQ
Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business.Our
company mainly produces Segment LED Displays.
Q: How long is your delivery time?
A: Delivery time:About 15-20 days; According to order quantity.
Q: What is your terms of payment?
A: T/T,Western Union,Paypal with small amount.
Q: How can I get your catalogue and price list?
A: Please let us know your email or contact us from website
directly for our catalogue and price list.
Q: Can I negotiate the prices?
A: Yes, we may consider discounts for multiple container load of
mixed goods.
Q: How much will the shipping charges be?
A: It depends on the size of your shipment and the method of
shipping.We will offer the charge to you as you requested.
Q: May I have some samples for testing?
A: Yes,we can provide 5-10pcs free samples in your delivery cost.
Round Common Cathode 7-Segment LED Temperature Display Controller
