Light Medium Duty 7 Ton Tipper Truck With Right Hand Driving Steering 4x2 Type

Brand Name:FAW
Certification:ISO9001
Model Number:CA3120P9A80
Minimum Order Quantity:1 unit
Delivery Time:30 DAYS
Place of Origin:Qingdao China
Contact Now

Add to Cart

Active Member
Location: Qingdao Shandong China
Address: Times Square, Cloud Avenue, Chongqing South Road, Qingdao, China
Supplier`s last login times: within 35 hours
Product Details Company Profile
Product Details

2 axles 4x2 Light Duty Dump Trucks 7 tons , LHD / RHD Tipper truck FAW , Utility Dump truck


This 7 tons 4x2 Utility Light Duty Dump Truck honor produced by FAW. It's 6 wheels medium duty dump truck.The six wheel dump truck is now a more common self-unloading car, which can be seen in many engineering projects. Because of its stable performance, good safety, relatively cheap price, and good performance in terms of energy consumption, it is always seen that this is a highly cost-effective dump truck. It is capable of large and medium-sized transportation needs in capacity, and can adapt to the transportation task requirements of engineering projects. In the future development, the car will continue to invest in the technical research and development force, which can provide more reliable guarantee and support for construction transportation.


Followed Our Product Advantages


(1) Competitive Factory Price and Excellent Quality
(2) Perfect after-sale service
(3) Export to more than 30 countries and regions
(4) One year quality guarantee or within 30000km, which comes first.
(5) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.


Specification of Dumper truck


Vehicle Description
TypeDump truckOverall Dimensions(mm)7405*2495*3060
GVW(kg)11995Mass in working order(kg)5850
Design Loading Weight(kg)6950Max speed(Km/h)80
Chassis Description
Chassis ModelCA3120Number of axles2
CabFAWAllowable Passengers In Cab3
Wheel base(mm)4090F/R track base(mm)1965/1860
F/R overhang(mm)1420/1985Approach/Departure angle(°)25/20
Spring plate10/10+9F/R axle-load4200/7795
Tire specification9.00-20Tire quantity6+1
Air conditionerOptionalType of fuelDiesel
Braking systemAir brakingElectric system24V
Traction system4*2Operation control systemSteering Wheel
Engine Description
Engine modelCA6110-125Engine manufactureFAW WUXI Diesel Engine Co., LTD
Exhaust(ml)4170Horse power180/210
Up-parts Description
Cargo body dimensions(mm)4300*2300*800
Cargo body materialCarbon steel Q235
Lifting systemEquipped with middle hydraulic system
Optional Configuration
Van thickness,side door,and other china brands hydraulic cylinder,etc.
