Float Function 2 Spool 40 liters monoblock valves 3/8'' spring return


We are professional manufacturer to produce Hydraulic Monoblock and Sectional Directional Control Valves to suit hydraulic systems of agricultural, forestry, construction, minging, transport, industrial, drilling machine, sanitation and many more


We have many options for the monoblock and sectional types

It's available from 40 liters - 200 liters, and upto 1 spools are also provided by us

Also manual, joystick, cable, pneumatic, solenoid, electro-pneumatic, electro-hydraulic control types

Ambient temperature-40C...+60C
Viscosity12 ...800 mm2/s
Fluid temperature-15C...+80C
Filtration10 to NAS 1638
Max operating pressure315 bar
Back pressure50 bar
Nominal flow40 l/min
Leakage(A,B-T)15cm3/min at 120bar
Spool stroke+/-7 mm
Actuating force< 200 N
Modification/ Spools1 to 8
Monoblock valveFlowNom. PressureSpool
P4040L/Min

E 16 MPa

F 20 MPa

1
P4040L/Min

E 16 MPa

F 20 MPa

2
P4040L/Min

E 16 MPa

F 20 MPa

3
P4040L/Min

E 16 MPa

F 20 MPa

4
P4040L/Min

E 16 MPa

F 20 MPa

5
P4040L/Min6
P8080L/Min

E 16 MPa

F 20 MPa

1
P8080L/Min

E 16 MPa

F 20 MPa

2
P8080L/Min

E 16 MPa

F 20 MPa

3
P8080L/Min

E 16 MPa

F 20 MPa

4
P8080L/Min

E 16 MPa

F 20 MPa

5
P8080L/Min

E 16 MPa

F 20 MPa

6
P120120L/Min

E 16 MPa

F 20 MPa

1
P120120L/Min

E 16 MPa

F 20 MPa

2
P120120L/Min

E 16 MPa

F 20 MPa

3
P120120L/Min

E 16 MPa

F 20 MPa

4
P120120L/Min

E 16 MPa

F 20 MPa

5
P120120L/Min

E 16 MPa

F 20 MPa

6
