EC Centrifugal Fan For Air Handling Unit AHU, BLDC Centrifugal Blower
Brand Name:trusTec
Certification:CE and LVD approval
Model Number:EC225
Minimum Order Quantity:200pcs
Delivery Time:20 work days fresh products after order confirmation.
Payment Terms:T/T, L/C
Contact Now
Add to Cart
Verified Supplier
Location:
Changzhou Jiangsu China
Address:
NO.38 Hongye Road, New Northern District, Changzhou City,213033, Jiangsu Province, China
Supplier`s last login times:
within 22 hours
Product Details
Company Profile
Product Details
EC centrifugal fans for air handling unit AHU, dc brushless centrifugal blower
Outline Dimension
Technical Parameter
| Model | Voltage /V | Operating Voltage /V | Frequency /Hz | Current /A | Input Power /W | Speed /RPM | Air Volume /m³/h | Static Pressure /Pa | N.W. /Kg | Noise /dB |
| EC120 | 230 | AC200-277 | 50/60 | 0.3 | 41 | 2200 | 240 | / | 1.8 | 62 |
| DC120 | 24 | DC16-28 | / | 1.9 | 40 | 2200 | 240 | / | 2.3 | 62 |
| DC120 | 48 | DC36-57 | / | 0.95 | 40 | 2200 | 240 | / | 2.3 | 62 |
| EC133 | 230 | AC200-277 | 50/60 | 0.3 | 38 | 1925 | 215 | / | 1.5 | 63 |
| DC133 | 24 | DC16-28 | / | 2.2 | 40 | 1925 | 215 | / | 1.3 | 64 |
| DC133 | 48 | DC36-57 | / | 1.1 | 45 | 1925 | 215 | / | 1.3 | 62 |
| EC140 | 230 | AC200-277 | 50/60 | 1.2 | 170 | 2770 | 425 | / | 3.2 | 63 |
| EC140 | 220 | AC200-277 | 50/60 | 0.5 | 66 | 1800 | 430 | / | 2.6 | 63 |
| DC140 | 24 | DC16-28 | / | 2.5 | 54 | 1800 | 430 | / | 2.3 | 63 |
| DC140 | 48 | DC36-57 | / | 1.3 | 54 | 1800 | 430 | / | 2.3 | 63 |
| EC146 | 230 | AC200-277 | 50/60 | 1.34 | 178 | 2520 | 620 | / | 3.6 | 72 |
| DC146 | 24 | DC16-28 | / | 5.0 | 100 | 2200 | 470 | / | 3.0 | 68 |
| DC146 | 48 | DC36-57 | / | 2.6 | 100 | 2150 | 465 | / | 3.0 | 67 |
| EC160 | 230 | AC200-277 | 50/60 | 1.35 | 180 | 2150 | 680 | / | 3.8 | 74 |
| DC160 | 24 | DC16-28 | / | 5.8 | 105 | 1750 | 505 | / | 3.0 | 67 |
| DC160 | 48 | DC36-57 | / | 2.9 | 105 | 1750 | 505 | / | 3.0 | 67 |
| EC180 | 230 | AC200-277 | 50/60 | 1.03 | 159 | 1330 | 900 | 70 | 4.0 | 72 |
| EC200 | 230 | AC200-277 | 50/60 | 3.1 | 510 | 1890 | 1590 | 150 | 7.2 | 73 |
| EC225 | 230 | AC200-277 | 50/60 | 3.5 | 545 | 1815 | 1600 | 300 | 10.3 | 77 |
| EC250 | 230 | AC200-277 | 50/60 | 2.9 | 450 | 1230 | 1900 | 180 | 14 | 78 |
EC Centrifugal Fan For Air Handling Unit AHU, BLDC Centrifugal Blower
