2 Axis CNC Spring Coiling Machine Automatic Compression Spring Machine

Brand Name:PM

Model Number:YLSK08

Minimum Order Quantity:1 SET

Delivery Time:10 DAYS

Payment Terms:L/C, T/T, Western Union

Place of Origin:CHINA

Contact Now

Add to Cart

Shanghai ProMega Trading Co., Ltd.

Verified Supplier

Location: Shanghai Shanghai China

Address: Room 302 No. 4 Alley 37 Zhang Jia Bang Road, Pudong New Area, Shanghai, China

Supplier`s last login times: within 27 hours

View Contact Details

Product Details Company Profile

Product Details

Spring coiling machine

Two Axis Compression Spring Machine, first is wire feed axis which controls wire feeding and second is cam axis which drives the cam to form the spring by controlling outside diameter, pitch & cutting blade. Machine is equipped with Torsion device, sutable for producing a variety of right or left handed torsion & special shape spring. Lenth detector device helps to detect & separate accurate springs. lenght tester & spring separator is optional device.

Controller system and Japanese servo motors provides high-speed, high precision, stable operation, no noise & vibration.

Machine can produce various types of compression springs, oil seal rings, conical sping, tension spring and special purpose springs.

Specifications:

Model	YLSK-08	YLSK-212
wire diameter(mm)	Φ0.15-Φ0.8	Φ0.3-Φ1.2
Axis count	2 Axis	2 Axis
outside diameter(mm)	max 20	max 32
max. feeding length	unlimited	unlimited
max. wire feed speed	110m/min	110m/min
cam seting value(mm)	±0.10~±359.90	±0.10~±359.90
servo motor of wire feed	0.75kw	1.0kw
servo motor of cam	0.75kw	1.0kw
machine size ( LWH)	7507001400mm	7508001400mm
Weight	350	450
Power	3 phase 380V AC 50HZ	3 phase 380v AC 50HZ

Company Profile

Shanghai ProMega Trading Co., Ltd. is a professional manufacturer producing qualified products and equipment in printing and packaging industry. Our company was established in 2008. We have 1 steel rule factory in Shanghai producing all kinds of steel rules, punches, ejection rubber, jigsaw blades, pins, doctor blade and creasing matrix in the Cutting formes industry.

Our main products are related to the Diecutting industry like Auto Bender, Laser cutter, Jigsaw machine, Diecutting machine, Hot stamping machine, Sampler maker, as well the machines in the after printing area such as Folder gluer, Guillotine machine, Laminator, Booking binding like cover machine, grooving machine, cardboard cutting machine, Dieboard making tools and consumables in Packaging and Printing industry.

We are specialized in the Diecutting industry which we can provide complete resolution of setting up a Dieshop for making Cutting formes and Block making for hot stamping or embossing areas. With our Auto Bender and Laser cutter, manual tools, users can set up or upgrade dieshop easily and raise efficiency greatly. We can provide not only the machines to set up dieshop, but also the software and management for this purpose.

Our company provide products to the world famous companies like GE Healthcare in Ireland and Norway, Cardinal Singapore, Apolo LTDA in Brazil, Kano Company Limited (Sandvik sole agent in Thailand)

Our main products as follows:

Steel rule

(Flat rule like Cutting rule/Creasing rule/Perforating rule, Cut-Crease rule/Wave rule/Zipper rule/Glue Flap rule; Rotary rule like Triangle teeth/Euro Cut/KK/Laser Crease/Tru Fold in shape SN, SNN, Curved)

Auto bender

(Korean style like YDWS with/without auto lipping/Japanese style like Mutli bender with/without broaching/Japanese and Korean combination style like Korean stick bending for small angle and Japanese panasonic servo driver feeding)

Laser cutting machine

(For Dieboard 18mm plywood Big power laser 1000W/1500W/2000W Rofin style by using 3 mixed gas from Gasket/400W or 600W laser by using CO2 laser tube/ Craft cutting laser by using 80W to 150W CO2 laser tube/ Laser marking machine by using 30W, 80W, 150W Rofin or Synrix laser tube)

Diecutting and Hot stamping machine

(Semi auto machine with heavy duty body and pressure, with beam protection and auto oil pump/ Fully auto machine like Bobst with/without stripping)

Folder gluer

(Folder gluer with stand box pasting and crash bottom function/ 4 corner or 6 corner Folder Gluer/ Corrugation carton folding and pasting )

Guillotine machine

(Similar to Polar style, LCD touch screen and program control, single or duel hydraulic driving)

Laminator

(Semi auto model with manual feeding with auto stop function and auto separating function/ Fully auto model with auto feeder, auto separate and vibrating collector)

Sample maker

(Sample maker like CNC router to Cardboard, Corrugation, Foam)

We are dedicated to not only provide high quality machines and consumables, but also complete resolution as per clients' requirement. We focus on the after sales service to build up fainth on our products. We believe in High quality with Reasonable prices to make all our clients get benefit by choosing our products and services.
