Electro - Hydraulic Servo Function Compression Testing Machine Computerized
Brand Name:LIYI
Certification:ISO
Model Number:WAW-600
Minimum Order Quantity:1 Piece
Delivery Time:15 days after receving deposit
Payment Terms:L/C, T/T, D/A, D/P, Western Union, MoneyGram
Contact Now
Add to Cart
Verified Supplier
Location:
Dongguan Guangdong China
Address:
Building 74, 96 kechuang road, Lianke Innovation Center, Nancheng District, Dongguan, Guangdong, China.
Supplier`s last login times:
within 1 hours
Product Details
Company Profile
Product Details
Computerized Electro-hydraulic Servo function of compression testing machine
Main specifications
Max. Test Force | 600KN | |
Calibration accuracy class | Class 1 | |
Column number | 4 | |
Force range | 20%-100% FS | |
Force Accuracy | Better than ±1% of reading | |
Extension range | 1%-100% FS | |
Extension accuracy | Better than ±1% of reading | |
Extension resolution | 1/350000 of max. extension | |
Actuator (piston) speed | 0 ~ 100mm/min | |
Clamping type | Manual & automatic clamping | |
Force loading speed | 0.02%-2%FS/s | |
Constant stress control range | 2~60N/mm2·S-1 | |
Constant strain control range | 0.00025/s~0.0025/s | |
Constant displacement control range | 0.5~50mm/min | |
Column spacing (test space width) | 500mm | |
Max. tension space | 600mm(customerized) | |
Max. compression Space | 550mm | |
Piston Stroke | 250mm | |
Diameter of threaded steel | Φ10 ~ φ40 | |
Tensile Fixture | Round specimen fixture | Ø13~Ø26mm Ø26~Ø40mm Ø40~Ø60mm |
Flat specimen fixture | 0~20mm 20~40mm | |
Flat size | 200mm*200mm | |
Bending adjust space | 600mm | |
Deformation testing device | Extensometer(customerized) | |
Overall Dimension(L*W*H) | 900*650*2200mm | |
Motor Power | 2.5KW | |
Weight | About 3500KG | |
Power supply | Three-phase 380V 50HZ | |
Technical terms of Frame
1. Lead screw driven cross head to adjust the test space
2. Dual Zone Test Space.
3. Automatic limit checking function.
4. The system return automatically & the oil cylinder should
return to the original position via manual or automatically after
finishing testing.
5. By the wedge action of hydraulic operated grips the specimen
holding.
6. High accuracy maintainable encoder.
